How Do I Choose a Sleeve Labeling Machine?

Views: 4733 Author: Howie SUN Publish Time: Update Time:
A labeller is the most frequent short stop on many lines, and the accumulator in front of it decides whether that stop reaches the filler.
Key facts at a glance
TypesSleeve, hot melt glue OPP, rotary sticker, self-adhesive
ThroughputMatched to the filler, with an accumulator between
Key controlLabel position, glue pattern, shrinkage, adhesion
MaterialOPP film, PVC or PETG sleeve, paper sticker
Key decisionFull sleeve or partial wrap
Line positionAfter filling, before packing

Sleeve, OPP or sticker: what decides the choice?

A full-body sleeve covers the whole bottle and gives the most design freedom, at the cost of film and a shrink tunnel. An OPP wrap-around label is the cheapest per unit at high speed. A sticker suits short runs and curved surfaces where a wrap is impractical.

Why does label position drift?

The label is positioned relative to the bottle, so any variation in bottle rotation, conveyor speed or label feed shows up as drift. On a round bottle the orientation is set by a roller or a star wheel; on a square bottle it is set by a mechanical aligner. Drift is usually a bottle handling problem, not a label problem.

Label typeCost per unitBest for
OPP wrap-aroundLowest at volumeHigh-speed round bottles
Full-body sleeveHigher film costFull coverage and shaped bottles
Self-adhesive stickerMiddleShort runs and flat or curved panels
Paper label with glueLow material, slowerGlass bottles and craft products

Throughput and change-part lists are on the Rotary Sticker Labeling page rather than in this note.

What does a shrink sleeve need from the bottle design?

A consistent circumference and no sharp undercut where the film cannot follow. Sleeves shrink around the shape, so a bottle with a deep waist needs a film with the right shrink direction. The bottle and the sleeve are designed together.

Reference unit for this duty: the Sleeve Labeling.

Why does a label need a vision check?

Because a missing or skewed label is a customer reject that the line cannot see. A camera at the labeller outlet with a reject gate catches it at the source, before the packer hides it inside a case.

The same question is worked through from another angle in How to Integrate Labeling and Packaging for Streamlined Workflow.

How to read the numbers. Treat the capacity figures as reference ranges from the product specification. Labelers lose rate to roll changes and glue build-up. Plan on a factor of 0.65-0.85 against the container rate.

Frequently asked questions

Why do labels wrinkle after shrinking?

Usually uneven tunnel temperature, wrong film orientation, or a bottle that is still warm from filling. Check the tunnel profile and the film direction before changing the speed.

Can one labeller run sleeve and OPP?

Not without a change of the applicator. Sleeve and wrap-around are different machines with different film paths, so a plant running both normally has two labellers.

What is the cheapest label per bottle?

At high volume, an OPP wrap-around label usually is, because the film is thinner and the machine runs faster. A sleeve costs more per unit but covers the whole bottle and allows full-body design.

How often should glue nozzles be cleaned?

On a fixed production interval set by the glue supplier and the plant, and immediately after any stop long enough for the glue to cure. A clogged nozzle shows as a missing glue line and a label that lifts in the pack.

Key takeaways
  1. Label type is a cost-per-unit decision before it is a design decision.
  2. Position drift is a bottle handling problem, not a label problem.
  3. The accumulator in front of the labeller protects the filler.
  4. A lifted seam is a glue and temperature question first.
About the author
Written by the Sunswell engineering team - led by Howie SUN, Founder & CEO, with 14 years in filling and blow-moulding equipment R&D and turnkey project delivery across 71+ countries.
Last reviewed: 2026-08-28 . Reviewed by Sunswell engineering team
×
