| Filling system | Piston dosing, or load cell for high-value product |
| Viscosity | Up to 10,000 cP with the right bore |
| Products | Sauces, pastes, pulp juice, honey, detergents |
| Package | PET, glass, jar, pouch by configuration |
| Key control | Dose repeatability, drip-free cut-off, product temperature |
| Cleaning | CIP circuit with a bypass for high-solid product |
A piston draws a fixed volume into a cylinder and pushes it out, so the dose does not depend on how fast the product flows. A gravity or pressure valve depends on flow time, and thick product makes that time unpredictable. For anything above a few thousand cP, the piston is the simpler answer.
High-solid product does not flush like water. The CIP circuit needs a pre-rinse at temperature, a bypass around the filler bowl, and a return path that does not leave product in a dead leg. Cleaning time on a sauce line is often longer than the production changeover, and both belong in the capacity plan.
| Product type | Dosing | Main risk |
|---|---|---|
| Smooth sauce | Piston | Drip at the nozzle |
| Chunky sauce | Piston with large bore | Bridging at the valve seat |
| Honey and syrup | Piston or load cell | Stringing and slow cut-off |
| Pulp juice | Piston | Fibre settling in the bowl |
The Filling Machine for Viscous Product is the matching unit when this becomes a line project.
Dose volume, piston stroke, suck-back, conveyor speed and often the nozzle set. A recipe change on a piston line is mostly mechanical, so it takes longer than a recipe change on a volumetric water line. Two very different products usually justify two fillers rather than one flexible one.
A different bottle format means a different unit; see the Filling Machine for Viscous Product.
From the largest particle, then from the dose volume. The bore has to pass the piece without bridging, and the valve seat has to close on the product rather than on the liquid around it. Speed comes last.
The same question is worked through from another angle in How to Select the Right Load Cell Combibloc for.
Yes, if the bore and the valve seat are sized for the largest particle. A filler set for smooth sauce will bridge on pulp, so the particle size is a specification input, not a detail.
Piston doses by displacement and is faster; load cell doses by weight and is more accurate when density varies. For a chunky product with variable density, weight filling avoids give-away.
It is set by the bore and the valve seat, not by the piston. Specify the largest piece in the product and size the seat above it, or the filler bridges and the dose falls short.
The suck-back stroke is too short for the viscosity, or the nozzle bore is too large. Both are settings, and both change when the recipe changes.
