What Is a Water Packing Machine? A Buyer's Guide

Views: 12539 Author: Howie SUN Publish Time: Update Time:
Shrink, carton and tray differ in cost per case and in what the pack has to survive, and the market decides before the machine does. For threaded bottles, the machine applies just enough pressure to secure the cap without causing damage.

Water Packing Machine

Key facts at a glance
TypesShrink wrap, wrap-around carton, carton packing, tray
RateMatched to the filler; usually the line bottleneck
Key controlFilm tension, seal temperature, case squareness
MaterialPE film, corrugated board, tray board
Key decisionShrink, carton or tray
Line positionAfter labelling, before palletizing

What actually decides the shortlist?

Four inputs fix the shortlist: the product, the package, the daily demand and the number of formats per week. Everything else, including the brand of the PLC, is a detail that can be settled after those four are written down.

Shrink, carton or tray: which one fits the market?

Shrink wrap is the cheapest per case and the fastest, and it suits retail where the pack is the display unit. A wrap-around carton gives print area and stack strength for distribution. A tray with shrink is a compromise used where the pack needs both protection and visibility.

Pack formatCost per caseWhat it protects
Shrink wrapLowestRetail display, short distribution
Tray + shrinkMiddleStacking and visibility
Wrap-around cartonHigherPrint area and long distribution
Regular slotted cartonHighest board useFragile packs and export

Site requirements, air and power consumption sit with the Carton Packing.

Why is the packer usually the line bottleneck?

A filler is rated on bottles per hour at a steady state; a packer is rated on cases per hour including film roll changes, seal cooling and pattern changes. Buyers compare the filler rating and forget that a packer rated below it sets the line rating for the whole shift.

This makes them ideal for large-scale production lines with speeds ranging from 5000 to 30,000 bottles per hour.

Rated output, change parts and services are listed on the Wrap-round Carton Packer page.

What makes a shrink pack fail in transit?

Film tension and seal temperature. A pack that is tight on the line but loose after cooling has been sealed too cold; a pack with a torn corner has been sealed too hot or cooled too fast. Both show up as returns, not as line stops, which is why they are easy to miss at commissioning.

For threaded bottles, the machine applies just enough pressure to secure the cap without causing damage.

The same question is worked through from another angle in The Role of Nitrogen Dosing in Water and Beverage.

How is film width chosen?

From the pack footprint plus the wrap allowance and the tunnel shrinkage. A film that is too narrow leaves the base exposed; too wide and the pack gets a double layer at the seam. Width is a per-format setting, like the lane guides.

How to read the numbers. Treat the capacity figures as reference ranges from the product specification. Packers are rated on a steady pack; jams and changeover sit outside that figure. Plan on 0.65-0.85.

Frequently asked questions

How many cases per hour is 24,000 BPH?

At 24 bottles per case, 1,000 cases per hour. The packer, the palletizer and the label supply all have to carry that number, and the line rating is the lowest of them.

What film thickness should a shrink pack use?

It follows the pack weight and the transport distance, and it is set with the film supplier. A thinner film saves cost per pack and fails earlier in a long distribution chain.

Why do bottles fall out of a shrink pack?

Usually insufficient wrap around the base or a seal that opened. Check the film width, the lap position and the seal temperature together, because changing one alone moves the failure elsewhere.

How many packs per minute does a shrink packer run?

It is rated in packs or cases per hour and must exceed the filler output in cases. The limiting factor is normally the tunnel dwell time, not the wrapping speed.

Can one packer run shrink and carton?

Not without a change of the packing module. Shrink and wrap-around carton are different machines with different board or film paths, so a plant running both normally has two packers.

Key takeaways
  1. The packer sets the line rating more often than the filler does.
  2. Shrink quality is film tension and seal temperature, and failures appear in transit.
  3. Tunnel dwell time usually limits the packer, not the wrapper.
  4. Case pattern is decided with the pallet, not after it.
About the author
Written by the Sunswell engineering team - led by Howie SUN, Founder & CEO, with 14 years in filling and blow-moulding equipment R&D and turnkey project delivery across 71+ countries.
Last reviewed: 2026-08-28 . Reviewed by Sunswell engineering team
×
