Water Filling Machines: How the Technology Evolved

Views: 6516 Author: Howie SUN Publish Time: Update Time:
The packer sets the line rating more often than the filler does, because it is rated in cases per hour including film changes and seal cooling. Integration of programmable logic controllers (PLCs) and human-machine interfaces (HMIs) further enhanced operational control.

water filling machine

Key facts at a glance
TypesShrink wrap, wrap-around carton, carton packing, tray
ThroughputMatched to the filler; usually the line bottleneck
Key controlFilm tension, seal temperature, case squareness
Contact materialPE film, corrugated board, tray board
Key decisionShrink, carton or tray
Line positionAfter labelling, before palletizing

Why is the packer usually the line bottleneck?

A filler is rated on bottles per hour at a steady state; a packer is rated on cases per hour including film roll changes, seal cooling and pattern changes. Buyers compare the filler rating and forget that a packer rated below it sets the line rating for the whole shift.

How does case pattern affect changeover?

A 4x6 pattern and a 3x4 pattern need different lane guides, different film width and often a different tunnel setting. On a semi-automatic packer the change is manual and takes tens of minutes; on an automatic packer it is a recipe, but only if the pattern was in the original specification.

Pack formatCost per caseWhat it protects
Shrink wrapLowestRetail display, short distribution
Tray + shrinkMiddleStacking and visibility
Wrap-around cartonHigherPrint area and long distribution
Regular slotted cartonHighest board useFragile packs and export

Site requirements, air and power consumption sit with the Wrap-round Film Shrink Wrapping.

How is film width chosen?

From the pack footprint plus the wrap allowance and the tunnel shrinkage. A film that is too narrow leaves the base exposed; too wide and the pack gets a double layer at the seam. Width is a per-format setting, like the lane guides.

The specification sheet for the Carton Packing carries the figures quoted here.

How is a packer matched to the filler?

In cases per hour, at the same format, with margin for film changes and seal cooling. A packer rated below the filler sets the line rating, and the shortfall appears as bottles accumulating before the packer rather than as a machine fault.

The same question is worked through from another angle in How to Choose a Shrink Wrapper for Your Water.

How to read the numbers. Capacity on these pages means the specification range, before any site-specific derating. Packers are rated on a steady pack; jams and changeover sit outside that figure. Plan on 0.65-0.85.

Frequently asked questions

How many cases per hour is 24,000 BPH?

At 24 bottles per case, 1,000 cases per hour. The packer, the palletizer and the label supply all have to carry that number, and the line rating is the lowest of them.

What film thickness should a shrink pack use?

It follows the pack weight and the transport distance, and it is set with the film supplier. A thinner film saves cost per pack and fails earlier in a long distribution chain.

Can a packer run 6-packs and 24-packs?

With different lane guides and a film width change, yes. The changeover is mechanical on a semi-automatic packer, so a plant selling both formats usually accepts a scheduled stop between runs.

Why does the film sag after the tunnel?

Too much heat, too little tension, or a film that is too thin for the pack weight. A pack that sags after cooling was sealed outside its window.

Key takeaways
  1. Case pattern is a specification item, not a changeover detail.
  2. Carton buys print and stack strength; shrink buys cost per case.
  3. Tunnel dwell time usually limits the packer, not the wrapper.
  4. Case pattern is decided with the pallet, not after it.
About the author
Written by the Sunswell engineering team - led by Howie SUN, Founder & CEO, with 14 years in filling and blow-moulding equipment R&D and turnkey project delivery across 71+ countries.
Last reviewed: 2026-08-28 . Reviewed by Sunswell engineering team
×
