| Types | Sleeve, hot melt glue OPP, rotary sticker, self-adhesive |
| Speed | Matched to the filler, with an accumulator between |
| Key control | Label position, glue pattern, shrinkage, adhesion |
| Wetted parts | OPP film, PVC or PETG sleeve, paper sticker |
| Key decision | Full sleeve or partial wrap |
| Line position | After filling, before packing |
A full-body sleeve covers the whole bottle and gives the most design freedom, at the cost of film and a shrink tunnel. An OPP wrap-around label is the cheapest per unit at high speed. A sticker suits short runs and curved surfaces where a wrap is impractical.
A consistent shrink needs the right film direction, a controlled tunnel temperature profile and a bottle that does not deform. Steam tunnels give a softer shrink than hot air and suit thin-wall bottles. A wrinkle at the shoulder is usually a film or temperature issue, not a speed issue.
| Label type | Cost per unit | Best for |
|---|---|---|
| OPP wrap-around | Lowest at volume | High-speed round bottles |
| Full-body sleeve | Higher film cost | Full coverage and shaped bottles |
| Self-adhesive sticker | Middle | Short runs and flat or curved panels |
| Paper label with glue | Low material, slower | Glass bottles and craft products |
Rated output, change parts and services are listed on the Rotary Sticker Labeling page.
Hot melt glue is applied at the leading and trailing edge and at the seam. The pattern, the pot temperature and the nozzle condition decide how much is used and how clean the bottle looks. Glue strings and smears are the usual complaint, and they come from temperature and nozzle wear.
The unit behind this configuration is the Sleeve Labeling.
Through the conveyor and an accumulator, not through a mechanical link. The labeller runs slightly faster than the filler and the accumulator absorbs the difference. A labeller matched exactly to the filler speed will stop the line at the first roll change.
The same question is worked through from another angle in How Labeling Accuracy Impacts Beverage Brand Image.
It is matched to the filler, typically with margin above the filler rating so that a short stop does not reach the filler. The practical limit is the shrink tunnel dwell time, not the sleeve applicator.
Not without a change of the applicator. Sleeve and wrap-around are different machines with different film paths, so a plant running both normally has two labellers.
On a fixed production interval set by the glue supplier and the plant, and immediately after any stop long enough for the glue to cure. A clogged nozzle shows as a missing glue line and a label that lifts in the pack.
Hot melt glue applied at the leading edge, the trailing edge and the seam. The pattern and the pot temperature decide both the bond and how clean the bottle looks.
Country:Kazakhstan
Product: PET Bottled Sparkling Water, Canned Soft Drink, Canned Tea
Capacity: 25000CPH (250ml)
Solution:Three Lines,7000BPH(1.5L), 15000CPH(330ml),15000CPH(450ml)
