| Filling method | Hot-fill, up to 85 C |
| Capacity range | 6,000-36,000 BPH at 0.2-2 L |
| Package | Heat-resistant PET geometry, or glass |
| Line | Hot-fill monobloc with tunnel pasteuriser |
| Products | Juice, tea, nectar, functional drinks |
| Key control | Fill temperature, hold time, cap seal |
Hot filling does two jobs at once: it pasteurises the product on the way to the filler, and the residual heat sanitises the bottle and cap. That is why a hot-fill line can run an acidic juice without a separate bottle steriliser. The price is a heat-resistant bottle and a longer cooling tunnel.
Temperature fluctuations in hotfill juice bottling lines can impact product stability and shelf life.
Tea usually needs finer filtration, deaeration to protect aroma, and a fill temperature that does not strip the volatile notes. Tea also clouds after cooling, so the clarification step is part of the product design, not a filling detail.
Optimize the hotfill process parameters to ensure consistent product temperatures throughout the bottling line.
| Route | Temperature | What it costs |
|---|---|---|
| Hot fill | Up to 85 C | Heat-resistant bottle and a cooling tunnel |
| Cold fill with preservative | Ambient | Formulation constraint, not a machine constraint |
| Cold fill with in-line pasteuriser | Product-side only | Separate pasteuriser and a closed filling zone |
| Hot fill in glass | Up to 85 C | Glass mass, slower line, higher transport cost |
Site requirements, air and water consumption sit with the Hotfill Type Filling Machine for Juice.
Glass brings mass, breakage and a slower line. It also brings a closure decision: crown, lug or screw. A glass hot-fill line usually runs at a lower rate than the same filler on PET, and the difference is handling and inspection, not the valve.
However, issues such as foaming, temperature fluctuation, and bottle cracks can disrupt the production process.
Where this becomes a line rather than a single machine, the Juice By Volumetric Filler is the starting point.
With a storage trial on the actual product, bottle and closure, held at the intended temperature and sampled on a schedule. Changing the fill temperature, the bottle or the cap invalidates the previous result, which is why those three are treated as one specification.
The same question is worked through from another angle in How Volumetric Fillers Ensure Consistent Juice Dispensing.
It replaces the bottle steriliser for acidic products, because the fill temperature and hold time do the microbial work. It does not replace correct product formulation or a validated hold tube.
It depends on the hold tube volume and the heater capacity. The line is not production-ready until the return temperature is stable, so start-up time belongs in the daily plan rather than being discovered at shift start.
With a filter change and a different valve bore for the pulp, yes. Clear juice needs finer filtration, and pulp needs agitation in the bowl so the fibre does not settle.
A controlled ramp rather than a cold plunge, so the bottle does not deform under vacuum. The tunnel zones are set per bottle geometry and validated with a temperature probe in the product.
