How to Design an Efficient Conveyor System for Your Bottling Line

Views: 2090 Author: Howie SUN Publish Time: Update Time:
The conveyor touches every bottle on the line, so guide rail gaps and transfer heights decide real uptime more than the filler rating does.
Key facts at a glance
What is includedAir conveyor, roller conveyor, depalletizer, palletizer
FunctionMove bottles and cases without damage, stack outbound pallets
Key controlAccumulation pressure, guide rail gap, pattern repeatability
TypesSemi-automatic and automatic palletizing
Key decisionManual, semi-automatic or robotic palletizing
AutomationManual, semi-automatic or robotic

Why does the conveyor decide how well the line runs?

The conveyor is the only part of the line that touches every bottle. Guide rail gaps, transfer plate height and accumulation pressure decide whether bottles jam, scuff or fall. Most unexplained short stops on a mature line trace back to a transfer that was set for one bottle format and never re-set.

When does automatic palletizing pay back?

Automatic palletizing pays when the labour it replaces is continuous and the pattern is stable. A plant running two shifts at high case rates reaches payback faster than a single-shift plant with mixed patterns, because a robot needs the pattern defined before it can be programmed.

FunctionManualAutomatic
Depalletizing empty bottlesRack or hand stackLayer depalletizer
Case palletizingOperator with pattern sheetLayer or robotic palletizer
Pallet wrappingHand wrapperIn-line stretch wrapper
AccumulationNone, line stops togetherBuffer sized to longest stop

The unit behind this configuration is the Conveying.

What breaks at the depalletizer?

Empty bottle layers are light and unstable, so the depalletizer is where a badly stacked pallet becomes a line stop. Layer pickup, sweep speed and the interface with the air conveyor are the three settings to check, and the pallet quality from the bottle supplier matters as much as the machine.

The specification sheet for the Depalletizing & Palletizing carries the figures quoted here.

How much accumulation does a line need?

Enough to cover the longest normal stop downstream without stopping the filler, and no more. Extra accumulation hides a problem instead of solving it, and it adds floor space plus a place for bottles to sit and collect dust. The buffer size is a calculation, not a default.

The same question is worked through from another angle in How Conveyor Layout Impacts Filling Line Productivity.

How to read the numbers. The capacity figures here are reference ranges taken from the product specification. Pattern changes and conveyor stops sit outside the rated figure, so plan on 0.65-0.85 of line speed.

Frequently asked questions

What is the difference between a depalletizer and a palletizer?

A depalletizer unloads empty bottles or full cases from a pallet at the start of a line. A palletizer stacks finished cases onto a pallet at the end. They are separate machines with separate footprints.

Why does a depalletizer drop layers?

Low air pressure, a worn layer clamp, or a pallet that is not square. Empty bottle layers are light, so small errors become fallen bottles at the infeed.

What conveyor speed should a line use?

It follows the filler rate with margin for accumulation, not the maximum the conveyor can carry. Running a conveyor faster than the line needs increases scuffing and jam severity.

When is a semi-automatic palletizer the right choice?

When the pattern is stable and the labour is available at the end of the line. It costs less and runs slower, and it needs an operator for every layer change.

Key takeaways
  1. The conveyor touches every bottle, so it decides the real uptime.
  2. Guide rail gap is a per-format setting, not an installation setting.
  3. Compare the pattern-adjusted palletizer rate, not the headline.
  4. Empty-bottle layers punish a badly squared pallet.
About the author
Written by the Sunswell engineering team - led by Howie SUN, Founder & CEO, with 14 years in filling and blow-moulding equipment R&D and turnkey project delivery across 71+ countries.
Last reviewed: 2026-08-28 . Reviewed by Sunswell engineering team
×
