CARBONATED
SOFT DRINKS (CSD)
FILLING MACHINE
/ Introduction
APPLICATION:
carbonated drinks, CSD, cola, soda water,
energy drinks, kvass, beer, etc.
CONTAINERS APPLIED FOR:
PET bottle of all volumes and shapes
FILLING SYSTEM:
isobaric filling
PRODUCTION CAPACITY:
3,000BPH – 24,000BPH (500ml)
/ Technical features
The air conveyor is directly connected with bottle-in starwheel. The bottle is transferred by
neck holding.
High speed line adopts bottle clamps to transfer the bottle. It makes work much easier when bottle size is changed.
By 3-in-1 monoblock, the bottle goes through rinsing, filling and capping with little abrasion,
and the transferring is stable, bottle change is easier.
Specially designed stainless steel bottle clamp dose not contact the thread parts of the bottle neck, avoiding the second contamination.
The high speed line is of ring type pressure bearing hydraulic cylinder.
High speed and large flow filling valve assures the high filling speed and exact fluid level.
Spares contact with the liquid are all of excellent stainless steel or food level plastic. The
electric system is of international brand and achieves the national food sanitary standard.
The bottle-out starwheel is of screwdown shape. When bottle size is changed, there is no
need to adjust the transferring chain’s height.
/ Equipment structure
Rack
Rotary
Rinser
Rotary
Carbonated
filler
Rotary
Capper
Bottle
infeed
and outfeed
system
Control

/ Technical parameter

Model DXGF18-18-6 DXGF24-24-6 DXGF24-32-6 DXGF40-40-10 DXGF50-50-12 RXGF72-72-15
Capacity
[BPH/500ml]
3000 6000 9000 12000 18000 24000
