Availability: | |
---|---|
Quantity: | |
TB
Sunswell
Features
* Full stainless steel protective of main engine the machine is fully waterproof and stainless;
* Adjustable blade base: Unique cut off, double blade for long using life
* Positioning center guiding pole: stable label guiding and delivering;
* Screw rod of separate bottle: stable transportation of bottles;
* Label brushing set: more accuracy of label-casing precision;
* Label control sensor shelf: original creation tail surface and sensor are combined to improve the precision of cutting the material.
*Human touch screen: Auto Show cause of the malfunction, operating more humane
* Touch-screen: operation humanization
* Separated rack: easier operation, more stable for high-speed label transport
S-450 Sleeve Labeler Configurations:
* PLC controller: Omron
* Stepping motor: Taida
* Step drivers: PANASONIC
* Transducer: Japan KEYENCE
* Touch screen: Taiwan Weinview
sleeve shrink wrapping machine and packaging equipment Technical Parameter:
Item | Parameters | |
1 | Host machine | AC220V, 50/60HZ, 1.5-2KW, single-phase |
2 | Capacity | 150BPM(faster if the label is shorter) |
3 | Diameter of bottle body | 28mm-125mm |
4 | Length of label | 30mm-250mm |
5 | Thickness of label | 0.035mm-0.13mm |
6 | Material of label | PVC, PET, OPS |
7 | Size of equipment | L2000*W850*H2000mm |
S-150/250 Label Sleever Technical Parameters:
* Size: 2100L*850W*2000H (mm)
* 2 meters conveyor belt include (motion and scraping belt are including)
* Gross weight: about 400KG
* Bottle diameter: 30-95mm(max)
* Bottle Height: 30-250mm
* Bottle type: round Bottle.
* Label length: 30~120 (mm)
* Label thickness: 0.03-0.13mm
* Paper pipe interior span: 5-10"
* Machine speed: 150/250BPM (subject to label length)
* Power: AC 3 phase, 380V
* Consumed power: 2.5KW
S-350 Label Sleever Technical Parameters:
* Size: 2000L*950W*2000H (mm)
* 2 meters conveyor belt (without motor)
* Gross weight: about 400KG
* Bottle diameter: 25-95mm(max)
* Bottle Height: 15-200mm
* Bottle type: round bottle
* Label length: 30-100mm (max)
* Label thickness: 0.03-0.08mm
* Paper pipe interior span: 3-10’’
* Machine speed: 300BPM (subject to label length)
* Power: AC 3¢380V
* Consumed power: 3KW
* Bottle type or big-and-small different, must change the center guide or infeed worm
* The label-casing machine controls the power of the conveyer belt in the machine
S-450 Label Sleever Technical Parameters:
* Size: 2000L*950W*2000H (mm)
* 2 meters conveyor belt include (motion and scraping belt are including)
* Gross weight: about 400KG
* Bottle diameter: 25-95mm (max)
* Bottle Height: 15-200mm
* Bottle type: round Bottle.
* Label length: 30~100 (mm)
* Label thickness: 0.030-0.080mm
* Paper pipe interior span: 3-10 ‘’
* Machine speed: 450BPM (subject to label length)
* Power: AC 3¢380V
* Consumed power: 3KW
RSS-2000 Steam Shrinker Technical Parameters:
* Size: 2000L*570W*900-1600H (mm)
* Power: AC 3¢380
* steam consumed capacity: 20-100 KG/H
* steam pressure: 0.15-0.4MPa
* Fan-power: 0.45-0.75KW
DZFZ-36KW Automatic Electric Steam Generator Technical Parameters:
* Rating: 36KW
* Power: 380V
* Consume power: 0.4Mpa
* Saturation steam temperature: 152°C
* Rating quanlity of steam occur: 45Kg/h
* Size: 1300L*700W*1000H (mm)
Bottle/Can Packing:
top of bottle | whole bottle | body to bottom | middle positioning |
Features
* Full stainless steel protective of main engine the machine is fully waterproof and stainless;
* Adjustable blade base: Unique cut off, double blade for long using life
* Positioning center guiding pole: stable label guiding and delivering;
* Screw rod of separate bottle: stable transportation of bottles;
* Label brushing set: more accuracy of label-casing precision;
* Label control sensor shelf: original creation tail surface and sensor are combined to improve the precision of cutting the material.
*Human touch screen: Auto Show cause of the malfunction, operating more humane
* Touch-screen: operation humanization
* Separated rack: easier operation, more stable for high-speed label transport
S-450 Sleeve Labeler Configurations:
* PLC controller: Omron
* Stepping motor: Taida
* Step drivers: PANASONIC
* Transducer: Japan KEYENCE
* Touch screen: Taiwan Weinview
sleeve shrink wrapping machine and packaging equipment Technical Parameter:
Item | Parameters | |
1 | Host machine | AC220V, 50/60HZ, 1.5-2KW, single-phase |
2 | Capacity | 150BPM(faster if the label is shorter) |
3 | Diameter of bottle body | 28mm-125mm |
4 | Length of label | 30mm-250mm |
5 | Thickness of label | 0.035mm-0.13mm |
6 | Material of label | PVC, PET, OPS |
7 | Size of equipment | L2000*W850*H2000mm |
S-150/250 Label Sleever Technical Parameters:
* Size: 2100L*850W*2000H (mm)
* 2 meters conveyor belt include (motion and scraping belt are including)
* Gross weight: about 400KG
* Bottle diameter: 30-95mm(max)
* Bottle Height: 30-250mm
* Bottle type: round Bottle.
* Label length: 30~120 (mm)
* Label thickness: 0.03-0.13mm
* Paper pipe interior span: 5-10"
* Machine speed: 150/250BPM (subject to label length)
* Power: AC 3 phase, 380V
* Consumed power: 2.5KW
S-350 Label Sleever Technical Parameters:
* Size: 2000L*950W*2000H (mm)
* 2 meters conveyor belt (without motor)
* Gross weight: about 400KG
* Bottle diameter: 25-95mm(max)
* Bottle Height: 15-200mm
* Bottle type: round bottle
* Label length: 30-100mm (max)
* Label thickness: 0.03-0.08mm
* Paper pipe interior span: 3-10’’
* Machine speed: 300BPM (subject to label length)
* Power: AC 3¢380V
* Consumed power: 3KW
* Bottle type or big-and-small different, must change the center guide or infeed worm
* The label-casing machine controls the power of the conveyer belt in the machine
S-450 Label Sleever Technical Parameters:
* Size: 2000L*950W*2000H (mm)
* 2 meters conveyor belt include (motion and scraping belt are including)
* Gross weight: about 400KG
* Bottle diameter: 25-95mm (max)
* Bottle Height: 15-200mm
* Bottle type: round Bottle.
* Label length: 30~100 (mm)
* Label thickness: 0.030-0.080mm
* Paper pipe interior span: 3-10 ‘’
* Machine speed: 450BPM (subject to label length)
* Power: AC 3¢380V
* Consumed power: 3KW
RSS-2000 Steam Shrinker Technical Parameters:
* Size: 2000L*570W*900-1600H (mm)
* Power: AC 3¢380
* steam consumed capacity: 20-100 KG/H
* steam pressure: 0.15-0.4MPa
* Fan-power: 0.45-0.75KW
DZFZ-36KW Automatic Electric Steam Generator Technical Parameters:
* Rating: 36KW
* Power: 380V
* Consume power: 0.4Mpa
* Saturation steam temperature: 152°C
* Rating quanlity of steam occur: 45Kg/h
* Size: 1300L*700W*1000H (mm)
Bottle/Can Packing:
top of bottle | whole bottle | body to bottom | middle positioning |
