Water Filling Machine

Introduction of Water FIlling Machine

Basic Info
APPLICATION:
still water, pure water, RO water, mineral water, sparkling water, alcoholic drinks, wine, etc.
CONTAINERS APPLIED FOR:
PET bottle
FILLING SYSTEM:
gravity filling
PRODUCTION CAPACITY:
5,000BPH – 36,000BPH (500ml)

Technical Features of Water Filling Machine

      It is adopted that direct connection between air conveyor and inlet starwheel instead of screw and conveyor chains, which is easier for bottle changing.
      There is no need to adjust the height of equipments through neck holding tech for bottle transportation. And what is only to change some spare parts.
      High speed filling line is of clamp transferring technology. Bottle shapes are more varied, and the working table inside the machine is more laconic.
      By 3-in-1 monoblock, the bottle goes through rinsing, filling and capping with little abrasion, and the transferring is stable, bottle changing is easier.
      Specially designed stainless steel bottle clamp dose not contact the thread parts of the bottle neck, avoiding the second contamination.
      High speed and large flow filling valve assures the high filling speed and exact fluid level.
      Spares contact with the liquid are all of excellent stainless steel or food level plastic. The electric system is of international brand and achieves the national food sanitary standard.
      The bottle-out starwheel is of screwdown shape. When bottle size is changed, there is no need to adjust the transferring chain’s height.

Technical Parameter of Water Filling Machine

Model XGF14-12-5 XGF16-16-5 XGF24-24-6 XGF32-32-8 XGF40-40-10 XGF60-60-15 XGFH72-50-18 XGFH80-60-20

Capacity

[BPH/500ml]

5,000 7,000 10,000 15,000 18,000 22,000 24,000 30,000 36,000

Structure of Water Filling Machine
